5, 8 Line Text Panels
TP05 / TP08 Series
Brand:
The screen of TP05 series can display five lines text or message at the same time and the screen of TP08 series can display eight lines text or message at the same time. These two series not only have the features of light weight, cost-effective price, good flexibility in use, and easy-to-control operation, but also supports various communication protocols, macro commands and software screen change functions.

  • STN LCD single color
  • TP05 series: 160*80 pixels / TP08 series: 240*128 pixels
  • 512K Flash Memory
  • 24 multiple function keys
  • Back-light auto turn off setting upon software
  • Power, Communication, Alarm LED
  • 2 Comm. Ports. It can communicate with different communication protocols simultaneously.
  • Provide program copy card function: Save download time.
  • Support Multi-Languages display
  • CE & UL approved

TITLE DOCUMENT TYPE SIZE
TP05 / TP08 Series Catalog 13926 KB
TP05 / TP08 Series Manual 2672 KB
