Standard Type Thyristor Power Controllers
DPU Series
Brand:
DPU Series are thyristor power controllers with fast, accurate, and precise control. The units feature accurate feedback control through RMS measurement and phase control and zero-cross cycle control are available. Remote monitoring and control are possible via RS485 communication for further user convenience.

  • High-speed, high-accuracy digital power control with high-speed CPU
  • Accurate feedback control (constant current, constant voltage, constant power) through RMS measurement
  • Phase control for various load control and zero-cross cycle control (fixed, variable cycles)
  • Built-in rapid fuse for internal circuit protection
  • Remote monitoring and control: Modbus RTU protocol via RS485 communication
  • Contains 6 customizable digital inputs
  • Various alarm outputs including current error or heater disconnection (partial disconnection detection)
  • Supports various control input signals (current, voltage, potentiometer)
  • Possible to install control unit independently
  • Applicable loads: super kanthal, platinum, molybdenum, carbon, halogen lamp, chrome, nickel, etc.

TITLE DOCUMENT TYPE SIZE
DPU series Manual 2702 KB
DAQMaster V2.7 Manual 9517 KB
DPU series (3-phase) Manual 1471 KB
DPU series (1-phase) Manual 9519 KB
DPU series Manual 1307 KB
DPU series Catalog 2340 KB
