Autonics, TC Series
Home > Product > Control Components > Temperature Controllers > TC Series
Single Display Temperature Controllers
TC Series
Brand:
Dual setting type temperature controller T4LP series can control heating and cooling at a time and realize high accuracy measurement of ±0.5% based on F•S value of each input. Also, it is dual setting type product that allows optimal low temperature controlling and high accuracy controlling. The series contributes to better user convenience by adopting digital switches.

  • Realizes ideal temp. controlling with newly developed PID control algorithm and 100ms high speed sampling
  • Built-in relay output or SSR output selectable : Enables to phase control and cycle control with SSR drive output (SSRP function)
  • Dramatically increased visibility using wide display part
  • Mounting space saving with compact design : Approx. 38% reduced size compared with existing model (depth-based)
  • SV/PV deviation indicatable

TITLE DOCUMENT TYPE SIZE
Temperature Controllers Selection Guide Manual 5244 KB
TC Series Manual 1014 KB
Temperature Controllers (Technical Description) Catalogue 416 KB
Temperature Controllers (Product Overview) Catalogue 1338 KB
TC/TD Series Common Features Catalogue 88 KB
TC Series Catalogue 1158 KB
