Push-in Interface Terminal Blocks
AFL Series
Brand:
The AFL series interface terminal blocks utilize screwless push-in type connection for quick and easy connection with even tightening, high vibration resistance, and secure, durable connection. The terminal blocks also feature a slim and compact design with 5 mm terminal pitch. The AFL series can be easily mounted with DIN rail locks or screw/bolt connection and are available in 20-pin, 40-pin, and 50-pin terminal models for diverse applications.

• Screwless push-in type connection for simple and easy connection
• Slim and compact design with 5 mm terminal pitch
• Ideal for connector type PLCs and dedicated controller I/O
• DIN rail mount and screw mount methods
• Available in 20-pin, 40-pin, and 50-pin terminal models


TITLE DOCUMENT TYPE SIZE
AFL Series Catalog 800 KB
AFL Series Manual 1374 KB
