Panasonic, SG-B1

Introducing a safety door switch with solenoid interlock that is among the world's thinnest*!
With 5 built-in contacts

* Based on research conducted by our company as of March 2013.

Space saving design with angled connection cable

SG-B1 series come with cables pre-installed.

The SG-B1 series ship with bundled cables already connected internally.
Since there is no need to provide cables separately, and because they are already connected internally, the number of wiring man-hours is cut in half.

Can be installed on any door.

Sliding doors

Hinged doors

Choose between two types of locks

• Spring lock
• Magnet lock

Easy-to-see LED operation indicator

SG-B1□

Safety door switch with solenoid interlock

Note 1: Drill mounting holes so that they are properly aligned for the orientation in which the safety switch will be used.

When using straight actuator (SG-K11)

Notes: 2) The actuator stop is used to adjust the actuator position. Remove the actuator stop after the actuator position is mounted.

When using the right-angle actuator (SG-K12 / SG-K12A)

Notes:

2)	The actuator stop is used to adjust the actuator position. Remove the actuator stop after the actuator position is mounted.
3)	41.4 1.63 when using SG-K12
*	The tensile strength of the SG-K12 actuator is 100N. If an excessive tensile force is applied, the actuator may fall off the door. When a tensile force exceeding 100N is expected, use the SG-K12A actuator with a plate.

When using the angle adjustable actuator (horizontal / vertical) (SG-K13 / SG-K14)

Notes: 2) The actuator stop is used to adjust the actuator position. Remove the actuator stop after the actuator position is mounted.

Actuator mounting reference position
As shown in the figure on the right, the mounting reference position of the actuator when inserted in the safety switch is:
The actuator stop on the actuator lightly touches the safety switch.
* The actuator stop is used to adjust the actuator position. Remove the actuator stop after the actuator position is mounted.

SG-K11

Actuator
Straight actuator

Note: The actuator stop is used to adjust the actuator position. Remove the actuator stop after the actuator position is mounted.

SG-K12

Actuator
Right-angle actuator

* The tensile strength of the SG-K12 actuator is 100N. If an excessive tensile force is applied, the actuator may fall off the door.
When a tensile force exceeding 100N is expected, use the SG-K12A actuator with a plate.

Note: The actuator stop is used to adjust the actuator position. Remove the actuator stop after the actuator position is mounted.

SG-K13

Actuator
Horizontal / vertical angle adjustable actuators (SG-K13)

* The base is made of glass-reinforced PA66 (66 nylon). Angle adjustment screws are stainless steel (SUS).
When using adhesive on screws, take material compatibility into consideration.

Note: The actuator stop is used to adjust the actuator position. Remove the actuator stop after the actuator position is mounted.

SG-K14

Actuator
Horizontal / vertical angle adjustable actuators (SG-K14)

* The SG-K14 differs from the SG-K13 in that the direction in which the metal parts on the tip of the actuator are embedded is reversed by 180°.

Note: The actuator stop is used to adjust the actuator position. Remove the actuator stop after the actuator position is mounted.

Changes in the orientation of adjustment for angle adjustable (horizontal / vertical) actuators
The orientation of actuator adjustment (horizontal / vertical) can be changed using the orienting insert (white plastic) installed on the back of the actuator.
Do not lose the mounting plate.

Manual unlocking key (Accessory: plastic)
